with 86 series dies, it allows aluminum terminal to be crimped through deep indent
18694 adapter is required to use the 84 series dies
with male quick coupling fitting with automatic locking
for operation it must to be combined with a pump with an operating pressure of 700 bar
| Details | |
| Product Category | heads for pumps up to 400 mm² |
| Crimping force at die level | 120 kN |
| Dies | 84 series and 86 series |
| Field of use | 84 series for terminals • uninsulated from 10 to 400 mm² (300 mm² for DIN) • uninsulated class 6 from 10 to 185 mm² • medium voltage from 25 to 400 mm² • aluminum from 16 to 240 mm² • bimetallic from 16 to 300 mm² • bimetallic DIN from 16 to 300 mm² • insulated from 10 to 240 mm² • C shunt from 10 to 150 mm² • end-sleeve from 50 to 150 mm² 86 series for deep indent of terminals • aluminum from 35 to 240 mm² |
| cid | 31AA14C |
